Technical Features
TECHNICAL FEATURES
|
MOTOR INSULATION CLASS |
F CLASS |
|
MOTOR PROTECTION CLASS |
IP 25 |
|
MOTOR EFFICIENCY CLASS |
– |
|
MOTOR ENCLOSURE TYPE |
OUTER ROTOR ENGINE |
|
MOTOR BRAND |
– |
|
BODY MATERIAL |
ABS PLASTIC |
|
BODY COATING |
– |
|
IMPELLER MATERIAL |
ABS PLASTIC |
|
DUTY CYCLE |
IEC Duty Cycle-S1 |
|
WORKING TEMPERATURE |
-20 – +50 °C |
|
STANDARDS |
IEC-60335-2-80, ISO 1940-1 |
TECHNICAL VALUES
| MODEL | VOLTAGE (V) | FREQUENCY (Hz) | POWER (W) | CYCLE (d/dk) | FLOW (m³/h) | SOUND LEVEL (dB(A)) |
| NYBF 100 | 230 | 50 | 14 | 2.800 | 107 | 35 |
| NYBF 125 | 230 | 50 | 18 | 2.800 | 190 | 36 |
| NYBF 150 | 230 | 50 | 22 | 2.800 | 300 | 38 |
