Technical Features
TECHNICAL FEATURES
| MOTOR INSULATION CLASS | F CLASS |
| MOTOR PROTECTION CLASS | IP 55 |
| MOTOR EFFICIENCY CLASS | IE2-IE3 |
| MOTOR ENCLOSURE TYPE | TEFC |
| MOTOR BRAND | VOLT |
| BODY MATERIAL | GALVANIZED SHEET METAL |
| BODY COATING | – |
| IMPELLER MATERIAL | GALVANIZED SHEET METAL |
| DUTY CYCLE | IEC Duty Cycle-S1 |
| WORKING TEMPERATURE | -20 – +50 °C |
| STANDARDS | IEC-60335-2-80, ISO 1940-1 |
TECHNICAL VALUES
| MODEL | VOLTAGE (V) | FREQUENCY (Hz) | POWER (kW) | CYCLE (d/dk) | FLOW (m³/h) | SOUND LEVEL (dB(A)) |
| NCLF 100 | 380 | 50 | 370 | 610 | 10.500 | 73 |
| NCLF 140 | 380 | 50 | 1.100 | 439 | 40.500 | 73 |
